Product information
The Viggen 9 from Razor is a very slim and bright LED extra light with a cocky look. With the lamp's TIR reflectors, you get more efficient light on the road and make the most of each LED on the auxiliary light. The Viggen 9 delivers a range of 938 meters @ 0.25 lux (469 meters @ 1 lux). The light pattern "Driving beam" is long and wide.
The Viggen 9 comes with lavish quality components, robust mount, pressure equalization membrane, EMC-secured components as well as stylish position lights that have the function of being able to choose between white or orange light!
Specification:
Installation instructions for cables are included with the product.
The Viggen 9 comes with lavish quality components, robust mount, pressure equalization membrane, EMC-secured components as well as stylish position lights that have the function of being able to choose between white or orange light!
Specification:
- Power: 120W (4 pcs 20W diodes & 4 pcs 10W diodes)
- Multivolt 9-36V DC
- Luminous flux: 12,000 lumens
- Burning time: 50,000 hours
- Light length with 1 lamp: 469m @ 1 Lux
- Light length with 3 lamps: 812m @ 1 Lux
- Finished attachment for stabilization brace
- Color temperature: 5700K
- IP68 dust and waterproof
- E-approved (ECE R112 & R10)
- Reference: 50
- Polycarbonate lens
- Aluminum lamp housing
- 9" - 218mm in diameter
- Height: 232mm (incl. bracket)
- Depth: 84mm
- Connector: DT-4 (adapter included to connect DT-3 cable set)
- Warranty: 3 years
Installation instructions for cables are included with the product.
- Red: Extra light (+)
- Black: Additional light/Position light (- earth)
- White: Position light (+) white light
- Yellow: Position light (+) yellow-orange light
