| Info | Compatible with |
Product information
Specifications
| Bolt Hole Circle Ø [mm]: | 108 |
| Bore Ø [mm]: | 13 |
| Brake Disc Thickness [mm]: | 8 |
| Brake Disc Type: | solid |
| Centering Diameter [mm]: | 71,1 |
| Fitting Position: | Rear Axle |
| Height [mm]: | 25,3 |
| Hole Ø [mm]: | 108 |
| Hole-Ø [mm]: | 13 |
| Inner Diameter [mm]: | 133,5 |
| Minimum thickness [mm]: | 6 |
| Number of bolts/screws: | 247 |
| Number of Holes: | 4 |
| Original number: | 169115 , 4246.G6 , 4246G3 , 4249 F5 , 95 661 749 , 96 012 770 |
| Outer Diameter [mm]: | 247 |
