| Info | Compatible with |
Product information
Specifications
| Bolt Hole Circle Ø [mm]: | 114,3 |
| Bore Ø [mm]: | 12,8 |
| Brake Disc Thickness [mm]: | 28 |
| Brake Disc Type: | Vented |
| Centering Diameter [mm]: | 68 |
| Fitting Position: | Front Axle |
| Height [mm]: | 49,1 |
| Hole Ø [mm]: | 114,3 |
| Hole-Ø [mm]: | 12,8 |
| Inner Diameter [mm]: | 144 |
| Minimum thickness [mm]: | 26 |
| Number of bolts/screws: | 280 |
| Number of Holes: | 5 |
| Original number: | 40206-3Y502 , 40206-3Y503 , 40206-4U101 , 40206-4U103 , 40206-4U105 , 40206-4U107 , 40206-U107 |
| Outer Diameter [mm]: | 280 |
